Phenogel 10<sup>4</sup> &Aring; GPC/SEC Columns<br class="t-last-br" />
Phenogel 104 Å has a molecular weight range of 5 K - 500 K

Phenogel 104 Å GPC/SEC Columns

The Optimal Choice for Aqueous and Mixed Organic Solutions

  • Molecular Weight Range: 5 K - 500 K
  • Recommended for use with resins
  • Wide range of solvent compatibility: packed in tetrahydrofuran (THF); additional shipping solvents (i.e. DMF, Toluene, Chloroform, and others) available on request
  • Temperature stable to 140 °C
  • Reduce solvent consumption and disposal costs up to 65% while retaining elution profile with Narrow Bore columns
  • Customize your analysis by coupling different pore size columns

Particle Size
5, 10
Recommended Use
Separation of resins (5 K - 500 K MW)

Applications on Phenogel Fixed Pore 104 Å
Non-Aqueous GPC/SEC Columns

Phenolic Resins

Columns:
Phenogel 5 µm 500 Å x 2, 103 Å, 104 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0443-K0 (500 Å)
00H-0444-K0 (103 Å)
00H-0445-K0 (104 Å)
Solvent:
THF
Flow Rate:
1 mL/min
Temperature:
25 °C
Detection:
Rl
Sample:
Phenolic Aldehyde Resin, MW 500 to 470 K

Polyvinyl Butyral

Columns:
Phenogel 5 µm 500 Å, 103 Å, 104 Å, 105 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0443-K0 (500 Å)
00H-0444-K0 (103 Å)
00H-0445-K0 (104 Å)
00H-0446-K0 (105 Å)
Solvent:
THF
Flow Rate:
1 mL/min
Temperature:
25 °C
Detection:
Differential Refractometer
Injection Volume:
100 µL 0.25 % w/v
Sample:
300,000 MW

Polyethylene Oxide (PEO)

Columns:
Phenogel 10 µm 103 Å, 104 Å, 105 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0444-K0 (103 Å)
00H-0445-K0 (104 Å)
00H-0446-K0 (105 Å)
Solvent:
DMF (0.1M LiBr)
Flow Rate:
1 mL/min
Temperature:
50 °C
Detection:
Differential Refractometer
Injection Volume:
100 µL 0.125 % w/v
Sample:
400,000 MW

Polystyrenes (Wide MW Range)

Columns:
Phenogel 10 µm 105 Å, 104 Å, 103 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0446-K0 (105 Å)
00H-0445-K0 (104 Å)
00H-0444-K0 (103 Å)
Solvent:
THF
Flow Rate:
1 mL/min
Detection:
Differential Refractometer
Injection Volume:
100 µL 0.25 % w/v
Sample:
1. 1,560,000 MW
2. 260,000 MW
3. 94,000 MW
4. 30,000 MW
5. 6,100 MW
6. 854 MW
7. 146 MW

Poly-(α-Methyl Styrene) (Wide MW Range)

Columns:
Phenogel 5 µm 105 Å, 104 Å, 103 Å, 500 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0446-K0 (105 Å)
00H-0445-K0 (104 Å)
00H-0444-K0 (103 Å)
00H-0443-K0 (500 Å)
Solvent:
THF
Flow Rate:
1 mL/min
Detection:
Differential Refractometer
Injection Volume:
100 µL 0.25 % w/v
Sample:
1. 680,000 MW
2. 90,000 MW
3. 30,000 MW
4. 6,000 MW

Polymethyl Methacrylates (Wide MW Range)

Columns:
Phenogel 5 µm 105 Å, 104 Å, 103 Å, 500 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0446-K0 (105 Å)
00H-0445-K0 (104 Å)
00H-0444-K0 (103 Å)
00H-0443-K0 (500 Å)
Solvent:
THF
Flow Rate:
1 mL/min
Detection:
Differential Refractometer
Injection Volume:
100 µL 0.25 % w/v
Sample:
1. 700,000 MW
2. 107,000 MW
3. 27,000 MW

Polybutadienes (Wide MW Range)

Columns:
Phenogel 5 µm 105 Å, 104 Å, 103 Å, 500 Å
Dimension:
300 x 7.8 mm
Part No.:
00H-0446-K0 (105 Å)
00H-0445-K0 (104 Å)
00H-0444-K0 (103 Å)
00H-0443-K0 (500 Å)
Solvent:
THF
Flow Rate:
1 mL/min
Detection:
Differential Refractometer
Injection Volume:
100 µL 0.25 % w/v
Sample:
1. 420,000 MW
2. 24,000 MW
3. 2,500 MW
4. 500 MW
